nRF91 Series SiP devices

Low power cellular IoT System-in-Package

nRF9160 SiP

Low power System-in-Package with integrated LTE-M/NB-IoT modem and GPS

  • LTE-M and NB-IoT support in bands from 700 MHz to 2.2 GHz
  • Worldwide operation
  • Up to +23 dBm output power
  • -108 dBm RX sensitivity (LTE-M)
  • Arm Cortex-M33
  • 1 MB flash + 256 kB RAM
  • Arm TrustZone + Arm CryptoCell
  • eDRX, PSM
  • SMS, IPv4/IPv6
  • TCP/UDP, TLS/DTLS
  • BSD secure socket, LTE L3 API’s
  • AT commands for control

nRF51 and nRF52 Series SoC devices

Low power short-range wireless System-on-Chip

nRF52810 SoC

Baseline nRF52 Series multiprotocol SoC optimized for wide market appeal and cost-constrained applications.

64 MHz Cortex-M4
192 KB Flash, 24 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps
Bluetooth 5
ANT
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI, PDM
PWM

12-bit ADC



nRF52811 SoC

Baseline nRF52 Series SoC with comprehensive protocol support, including Bluetooth 5.1 Direction Finding.

64 MHz Cortex-M4
192 KB Flash, 24 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, Long Range
Bluetooth 5.1 Direction Finding
ANT, 802.15.4, Thread, Zigbee
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI, PDM
PWM

12-bit ADC



nRF52832 SoC

General-purpose nRF52 Series multiprotocol SoC with high performance and broad peripheral set.

64 MHz Cortex-M4F
512/256 KB Flash, 64/32 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps
Bluetooth 5, Bluetooth mesh
ANT
+4 dBm TX Power
128-bit AES CCM
UART, SPI, TWI, PDM, I2S
PWM
12-bit ADC

NFC-A


nRF52840 SoC

High-end nRF52 Series multiprotocol SoC for high-performance, feature-rich applications with best-in-class security.

64 MHz Cortex-M4F
1 MB Flash, 256 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, Long Range
Bluetooth 5, Bluetooth mesh
ANT, 802.15.4, Thread, Zigbee
+8 dBm TX Power
128-bit AES CCM, ARM CryptoCell
UART, SPI, TWI, PDM, I2S, QSPI
PWM
12-bit ADC
NFC-A
USB 2.0

nRF51822

General purpose Bluetooth Low Energy SoC ideal for single chip solutions or as a connectivity device.

16 MHz Cortex-M0
256/128 KB Flash, 32/16 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, 250 kbps
Bluetooth Low Energy
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI

10-bit ADC

nRF51422

General purpose multiprotocol ANT/Bluetooth Low Energy SoC. It is a nRF51822 with ANT support.

16 MHz Cortex-M0
256/128 KB Flash, 32/16 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, 250 kbps
Bluetooth Low Energy, ANT
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI

10-bit ADC

nRF51824

nRF51824 is a AEC Q100 Grade 2 qualified Bluetooth Low Energy SoC. It is an auto grade nRF51822.

16 MHz Cortex-M0
256 KB Flash, 16 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, 250 kbps
Bluetooth Low Energy
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI

10-bit ADC

AEC-Q100

nRF51802

General purpose Bluetooth Low Energy SoC for cost-sensitive applications.

16 MHz Cortex-M0
256 KB Flash, 16 KB RAM
2.4 GHz Transceiver
2 Mbps, 1 Mbps, 250 kbps
Bluetooth Low Energy
+4 dBm TX Power
128-bit AES CCM

UART, SPI, TWI

10-bit ADC

}
