nPM1100 Thumbnail

Congratulations!

If you're reading this you are one of the few people lucky enough to receive a nPM1100 Thumnail board from one of our representatives. The nPM1100 Thumbnail is a giveaway board for showing off the nPM1100's capabilities as a small, highly efficient PMIC that requires very little board space to be fully operational. The nPM1100 Thumbnail features a fully functional nPM1100 PMIC and the passive components required to make it operate, with solder pads for select pins on the nPM1100 on a 100 mil grid. It can thus be used as a daughterboard by soldering it to a prototyping board. It can be used for powering applications with a regulated 3.0 V supply and charging lithium-ion and lithium polymer batteries via USB. For instructions see the user guide below. To read more about the nPM1100 download the product brief, or visit the nPM1100 product page.

Download PDF  Download nPM1100 product brief [PDF]

Ask us about this
Key features
  • Inductor choices optimized for size
  • Requires no software to operate
  • 3.0 V regulated output
  • USB input
  • Battery charging and power delivery
  • Solder pads to essential pins on nPM1100
  • Solder pads on a 100 mil grid for easily integrating with prototyping boards
Downloads

How to use it

Connector

Description

What to connect to

D_N
D_P

USB Data-
USB Data+

Positive and negative data lines of USB for port detection.
If unused connect D_N to ground for static 100 mA current limit.

VBUS

USB power input

Connect to 5 V USB power for charging.

VBAT

Battery

Positive terminal on battery.

NTC

Battery temperature

Battery thermistor, if unused connect to ground via 10 kΩ resistor.

GND

Ground

System ground.

CHG
ERR

Charge and error indication

Connect to indicator LEDs, optional, if unused leave open.

VOUTB

Regulated output

Outputs 3.0 V regulated.

VSYS

System voltage

Outputs battery voltage or USB voltage.


A picture of a very small IC surronded by small capacitors and an inductor, with a matchstick head for scale
